Vertical Oil Clarifier Setting Tank With Stirrer

Vertical Oil Clarifier Setting Tank With Stirrer Function and Working Method

The Vertical Oil Clarifier Setting Tank operates by combining heating and mechanical stirring to separate water and impurities from crude palm oil in the clarification process in palm oil mill, often working in coordination with upstream equipment such as the transfer carriage palm oil mill system. This essential palm oil clarifier is equipped with a heating system that uses both indirect and direct steam to raise the oil temperature. Reducing the oil's viscosity facilitates the settling of water and impurities. Simultaneously, a slow-rotation stirrer ensures gentle yet thorough mixing, distributing heat evenly and preventing stratification, thereby enhancing the efficiency of oil clarification.

Vertical Oil Clarifier Setting Tank With Stirrer Material and Construction

Constructed from stainless steel 304, this oil clarifier combines durability with corrosion resistance. The material ensures the tank withstands high temperatures and continuous operation in a palm oil mill environment while preventing oil contamination, thereby maintaining quality throughout the clarification process in palm oil mill.

Vertical Oil Clarifier Setting Tank With Stirrer Key Features

• Size Diameter: The palm oil clarifier has a diameter of 4500 mm, providing a large capacity for efficient oil processing.

• Capacity: This vertical clarifier tank palm oil mill system is designed to handle a capacity of 160 m³, making it suitable for large-scale palm oil processing operations.

• Driver Model: The stirrer is driven by a reducer motor connected directly to the main shaft, ensuring efficient power transmission and smooth operation.

• Stirrer Speed: Operates at a slow rotational speed of 3 rpm, ensuring gentle mixing of the oil while promoting effective separation of water and residues.

• Power: Equipped with a motor rated at 1450 rpm, 4 kW, 380 V, and 50 Hz, providing sufficient energy for reliable stirring action.

• Heating Type: Utilizes a combination of indirect steam and direct steam for efficient and even heating of the crude palm oil.

Vertical Oil Clarifier Setting Tank With Stirrer Performance Advantages

• Efficient Clarification: The combination of heating and gentle stirring ensures effective separation of water and impurities, producing high - quality clarified palm oil.

• Durable and Corrosion - Resistant: The stainless steel 304 construction ensures long - term reliability and minimal maintenance requirements.

• Large - Capacity Operation: With a capacity of 160 m³, the tank can handle high - volume processing demands, ensuring efficient workflow in large - scale palm oil mills.

• Energy - Efficient Heating: The use of indirect and direct steam ensures efficient heat transfer and minimal energy consumption during the heating process.

• Stable Operation: The slow stirrer speed and robust design ensure stable and continuous operation, with minimal risk of oil degradation or emulsification.

Vertical Oil Clarifier Setting Tank With Stirrer Applications

This vertical clarifier tank is widely used in palm oil mill and processing plants. Installed after oil extraction, it serves as a key palm oil clarifier to treat crude oil before refining or storage. Its design integrates seamlessly into both new and existing facilities, enhancing the efficiency and output of the clarification process in palm oil mill.
