Tubular Heater

Tubular Heater Function and Working Method

The Tubular Heater operates by utilizing steam to heat crude glycerin. The crude glycerin flows through a series of tubes, while steam circulates in the shell side of the heater. The heat from the steam is transferred through the tube walls to the crude glycerin, raising its temperature to the desired level. This indirect heating method ensures efficient and controlled temperature adjustment of the crude glycerin.

Tubular Heater Material and Construction

Constructed from 0Cr18Ni9 stainless steel, the Tubular Heater combines excellent corrosion resistance with high - temperature strength. This material choice ensures that the heater can withstand the rigorous conditions of continuous operation, including exposure to high - temperature steam and liquid glycerin. The stainless steel construction also prevents contamination of the crude glycerin, maintaining its purity and quality throughout the heating process.

Tubular Heater Key Features

• Working Method: The heater uses steam to heat crude glycerin indirectly through tubular heat exchange, ensuring efficient temperature adjustment.

• Material: Made from 0Cr18Ni9 stainless steel, ensuring corrosion resistance and suitability for industrial applications.

• Media: Designed to heat liquid crude glycerin and uses steam as the heating medium.

• Work Pressure: Operates at a working pressure of 0.3 MPa, ensuring safe and efficient heat transfer.

• Jacket Pressure: The steam jacket operates at a pressure of -0.10 MPa (vacuum), creating the necessary conditions for efficient heating.

• Working Temperature: The crude glycerin is heated to a working temperature of 143℃ , optimizing its viscosity and flow properties for subsequent processing.

• Jacket Temperature: The steam jacket reaches a temperature of 110℃ , providing sufficient heat for the heating process.

• Equipment Size: The size of the heater is determined based on the required production capacity, ensuring efficient and scalable operation.

• Production Standard: Manufactured in compliance with GB150-1998 《Shell and Tube Heat Exchanger Vessels》, ensuring the equipment meets stringent safety and quality standards.

Tubular Heater Performance Advantages

• Efficient Heating: The tubular heat exchanger design ensures efficient transfer of heat from the steam to the crude glycerin, achieving rapid and uniform temperature adjustment.

• Durable Construction: The 0Cr18Ni9 stainless steel material ensures long - term reliability and resistance to corrosion and high - temperature conditions.

• Stable Operation: The heater is designed for stable and continuous operation, with precise control of temperature and pressure parameters.

• Energy - Efficient Operation: The steam heating system ensures efficient heat transfer, minimizing energy consumption while maintaining optimal heating conditions.

• High - Purity Outputs: The indirect heating method prevents contamination of the crude glycerin, maintaining its purity and quality throughout the heating process.

Tubular Heater Applications

The Tubular Heater is widely used in chemical processing plants, biodiesel production facilities, and other industrial settings where heating of crude glycerin or similar liquids is required. It is typically installed before purification or refining stages to ensure the crude glycerin is at the optimal temperature for further processing. Its design and specifications make it suitable for integration into both new and existing processing facilities, enhancing their overall efficiency and product quality.
