Palm Kernel & Shell Separate Winnowing System

Palm Kernel & Shell Separate Winnowing System Function and Working Method

The winnowing system operates based on pneumatic and gravity principles. The process involves the use of air currents to separate the lighter shells from the heavier kernels. The material to be separated is fed into the system, where a powerful fan generates an airflow that lifts and carries the lighter kernels away from the heavier shells. The kernels and shells are then collected in separate compartments. The system's design ensures optimal separation efficiency by carefully controlling the air volume and pressure, as well as the trajectory of the materials.

Palm Kernel & Shell Separate Winnowing System Material and Construction

Constructed from carbon steel, the winnowing system combines strength and durability. Carbon steel is chosen for its excellent mechanical properties, including high tensile strength and wear resistance, making it ideal for withstanding the continuous operation and material flow typical in a palm oil mill environment.

Palm Kernel & Shell Separate Winnowing System Key Features

• Volume/Pressure: The system is designed to handle an air volume of 19,500 m³/hr at a pressure of 250 mmWG, ensuring sufficient airflow for effective separation of kernels and shells.

• Fan Model: Equipped with a centrifugal fan, which is known for its high - efficiency air movement and ability to generate the required airflow and pressure for the separation process.

• Driver Model: The fan is driven by a motor connected directly to the main shaft, ensuring efficient power transmission and smooth operation.

• Capacity: Designed for a capacity of 10 tons per hour, making it suitable for medium - scale palm oil processing operations.

• Fan Power: Powered by a motor rated at 2200 rpm, 22 kW, 380 V, and 50 Hz, providing the necessary energy to generate the required airflow.

• Air Lock Size: Features air locks with sizes of 320 mm and 480 mm, each powered by a 1.5 kW motor, to control the flow of material into and out of the separation zone, ensuring a continuous and efficient process.

Palm Kernel & Shell Separate Winnowing System Performance Advantages

• Efficient Separation: The combination of pneumatic and gravity principles ensures highly efficient separation of kernels and shells, producing a clean kernel product suitable for oil extraction.

• Durable Construction: The carbon steel build ensures long - term reliability and minimal maintenance requirements, even under continuous and demanding operating conditions.

• High - Capacity Operation: With a capacity of 10 tons per hour, the system can keep up with the processing demands of palm oil mills, ensuring efficient workflow and high productivity.

• Energy - Efficient Operation: The fan and motor are designed to minimize energy consumption while maintaining high - performance air separation.

• Continuous Process: The air locks facilitate a continuous feeding and discharge process, enhancing the overall efficiency and throughput of the system.

Palm Kernel & Shell Separate Winnowing System Applications

The Palm Kernel & Shell Separate Winnowing System is an essential component in palm oil mills and processing plants. It is typically installed after the nut polishing drum and before the kernel drying and storage stages. By effectively separating kernels from shells, the system ensures that only high - quality kernels are processed further for oil extraction, improving the overall efficiency and yield of the palm oil production process. Its design and specifications make it suitable for integration into both new and existing palm oil processing facilities, enhancing their ability to produce high - quality palm kernel oil.
