Palm Fruit Twin Screw Press

Palm Fruit Twin Screw Press Function and Working Method

The Twin Screw Press operates by utilizing two intermeshing screws within a barrel. As the screws rotate, they compress and shear the palm fruit, generating heat through friction. This heat helps to reduce the viscosity of the oil, making it easier to separate from the fruit solids. The screw design and rotation speed are optimized to provide gentle yet effective mechanical pressing, maximizing oil extraction while minimizing fruit cell damage and energy consumption.

Palm Fruit Twin Screw Press Material and Construction

The body of the Twin Screw Press is constructed from carbon steel, providing robustness and durability for heavy - duty industrial applications. Selected components that come into contact with the palm fruit and oil, such as the screws and barrel, are made from stainless steel 304. This ensures resistance to corrosion and contamination, maintaining the quality and hygiene of the extracted oil.

Palm Fruit Twin Screw Press Key Features

• Outside Size: 4600 mm × 1100 mm × 1400 mm, making it a compact yet powerful addition to palm oil processing facilities.

• Weight: Weighing 4500 kg, the machine is built to withstand the intense mechanical forces and continuous operation typical in the industry.

• Driver Model: The press is driven by a motor coupled to a gear reducer via a belt. The gear reducer output shaft is connected to the main shaft by a coupling, ensuring efficient power transmission and smooth operation.

• Capacity: Available in capacities of 3500 liters and 4500 liters, allowing it to handle varying processing volumes.

• Power: Equipped with a motor rated at 1450 rpm, 30 kW, 380 V, and 50 Hz, providing sufficient power for reliable performance.

• Rotational Speed: The screws rotate at a speed of 8 - 11 rpm, optimizing the pressing process for efficient oil extraction with minimal energy consumption.

• Hydraulic Driver: The machine is equipped with a hydraulic oil box to power any hydraulic components, ensuring precise control and additional mechanical assistance if needed.

• Oil Loss Control: Designed to maintain oil loss at ≤8%, it ensures high - efficiency oil extraction and minimal waste, contributing to cost - effective operation and resource conservation.

Palm Fruit Twin Screw Press Control System

The Twin Screw Press is equipped with an advanced PLC Control system. This system allows for automated and precise control of the pressing process. It enables operators to monitor and adjust critical parameters such as rotational speed, temperature, and pressure. The PLC system also facilitates integration with other equipment in the processing line, ensuring seamless and efficient operation throughout the entire production process.

Palm Fruit Twin Screw Press Performance Advantages

• High - Efficiency Oil Extraction: The combination of screw warming technology and optimized rotational speed ensures maximum oil recovery from the palm fruit.

• Durable and Robust Construction: The use of carbon steel and stainless steel 304 materials ensures long - term reliability and minimal maintenance requirements.

• Flexible Capacity: Multiple capacity options make it suitable for operations of various scales, from medium to large - scale palm oil processing facilities.

• Energy - Efficient Operation: The rotational speed and power specifications are designed to minimize energy consumption while maintaining high - performance oil extraction.

• Advanced Automation: The PLC Control system reduces manual intervention, enhances process consistency, and ensures efficient operation and monitoring.

Palm Fruit Twin Screw Press Applications

The Twin Screw Press is an essential component in palm oil mills and processing plants. It is primarily used after the sterilization and threshing processes to extract crude palm oil from the fruit mesocarp. Its design and specifications make it suitable for integration into both new and existing palm oil processing facilities, enhancing their oil extraction efficiency and productivity.
