Horizontal Type Sterilizer Tank

Horizontal Type Sterilizer Tank Working Conditions

• Pressure and Temperature: The sterilizer operates at a working pressure of 3.5 kg/cm² and a temperature of 135℃ , creating the ideal conditions for steam to penetrate and sterilize the FFB.

• Steam Usage and Cycle Time: With a steam consumption rate of 220 - 270 kg per ton of FFB and a sterilization cycle time of 55 - 60 minutes, the equipment balances efficiency and effectiveness.

Horizontal Type Sterilizer Tank Specifications

• Dimensions and Capacity: The outside diameter options of 2700 mm and 3200 mm, coupled with a capacity of 20 - 55 tons per unit, make this sterilizer versatile for different production scales.

• Discharge Mechanism: The Fruit Cage and Tippler discharge method ensures gentle and efficient removal of sterilized FFB from the tank.

• Sealing and Door Design: The hydraulic door, sized at 2700 mm or 3200 mm, provides a tight seal to maintain the sterilization environment and is designed for durable operation.

Horizontal Type Sterilizer Tank Control Features

The sterilizer is equipped with a PLC Indexer Control system that automates and optimizes the sterilization process. This system allows for precise control of all operational parameters, ensuring consistent performance and easy management of the sterilization cycles.

Horizontal Type Sterilizer Tank Benefits

• Effective Microorganism Elimination: The high - temperature steam effectively kills harmful microorganisms, preserving the quality and integrity of the FFB.

• Scalable Production: The capacity range allows the equipment to adapt to the needs of various palm oil mills, from medium to large - scale operations.

• Durable and Low - Maintenance: The robust construction and hydraulic sealing system reduce maintenance requirements and ensure long - term reliable service.

• Advanced Automation: The PLC system reduces operational errors and labor intensity, making the sterilization process more efficient and manageable.

Horizontal Type Sterilizer Tank Use Cases

This horizontal sterilizer is widely used in palm oil processing facilities where efficient and large - scale FFB sterilization is required. It is an integral part of the production line, working in conjunction with other equipment such as threshers and digesters to streamline the oil extraction process.
