Fatty Acid Heater

Fatty Acid Heater Function and Working Method

The Fatty Acid Heater operates by circulating thermal oil through a jacket surrounding the heating chamber. The fatty acid is pumped into the chamber where it indirectly receives heat from the thermal oil. This indirect heating method ensures precise temperature control and uniform heating of the fatty acid, making it suitable for applications that require specific temperature conditions.

Fatty Acid Heater Material and Construction

Constructed from 00Cr17Ni14Mo2 stainless steel, the Fatty Acid Heater combines excellent corrosion resistance with high - temperature strength. This material choice ensures that the heater can withstand the rigorous conditions of continuous operation, including exposure to high - temperature thermal oil and fatty acids. The stainless steel construction also prevents contamination of the fatty acid, maintaining its purity and quality throughout the heating process.

Fatty Acid Heater Key Specifications

• Working Method: The heater uses thermal oil to heat fatty acids indirectly through a jacketed design, ensuring efficient and controlled temperature adjustment.

• Material: Made from 00Cr17Ni14Mo2 stainless steel, ensuring corrosion resistance and suitability for high - temperature applications.

• Media: Designed to heat fatty acids and uses thermal oil as the heating medium.

• Design Pressure: Operates at a design pressure of 0.1 MPa, ensuring safe and efficient heat transfer.

• Jacket Pressure: The thermal oil jacket operates at a pressure of -0.1 MPa (vacuum), creating the necessary conditions for efficient heating.

• Working Temperature: The fatty acid is heated to a working temperature of 280℃ , optimizing its viscosity and flow properties for subsequent processing.

• Jacket Temperature: The thermal oil jacket reaches a temperature of 240℃ , providing sufficient heat for the heating process.

• Equipment Size: The size of the heater is determined based on the required production capacity, ensuring efficient and scalable operation.

• Production Standard: Manufactured in compliance with GB150-1998 《Shell and Tube Heat Exchanger Vessels》, ensuring the equipment meets stringent safety and quality standards.

Fatty Acid Heater Performance Advantages

• Efficient Heating: The jacketed design ensures efficient transfer of heat from the thermal oil to the fatty acid, achieving rapid and uniform temperature adjustment.

• Durable Construction: The 00Cr17Ni14Mo2 stainless steel material ensures long - term reliability and resistance to corrosion and high - temperature conditions.

• Stable Operation: The heater is designed for stable and continuous operation, with precise control of temperature and pressure parameters.

• Energy - Efficient Operation: The thermal oil heating system ensures efficient heat transfer, minimizing energy consumption while maintaining optimal heating conditions.

• High - Purity Outputs: The indirect heating method prevents contamination of the fatty acid, maintaining its purity and quality throughout the heating process.

Fatty Acid Heater Applications

The Fatty Acid Heater is widely used in chemical processing plants, biodiesel production facilities, soap and detergent manufacturing, and other industrial settings where heating of fatty acids is required. It is typically installed before processes such as esterification, refining, or blending to ensure the fatty acids are at the optimal temperature for reaction or mixing. Its design and specifications make it suitable for integration into both new and existing processing facilities, enhancing their overall efficiency and product quality.
