Fatty Acid Flash Separation Tank

Fatty Acid Flash Separation Tank Function and Working Method

The Fatty Acid Flash Separation Tank operates by introducing high - pressure fatty acids into a low - pressure environment within the tank. When the fatty acids enter the tank, the sudden drop in pressure causes their boiling point to decrease. Since the temperature of the fatty acids is higher than the new boiling point at the reduced pressure, the water content quickly boils and vaporizes. This process results in the separation of gases from the liquid fatty acids.

Fatty Acid Flash Separation Tank Material and Construction

Constructed from 00Cr17Ni14Mo2 stainless steel, the Fatty Acid Flash Separation Tank combines excellent corrosion resistance with high - temperature strength. This material choice ensures that the tank can withstand the rigorous conditions of continuous operation, including exposure to high - temperature fatty acids and steam.

Fatty Acid Flash Separation Tank Key Specifications

• Working Method: Utilizes a flash separation process where high - pressure fatty acids are introduced into a low - pressure environment, causing rapid vaporization of water and separation of gases.

• Material: Made from 00Cr17Ni14Mo2 stainless steel, ensuring durability and resistance to corrosion.

• Media: Designed to process crude glycerin and steam.

• Work Pressure: Operates at a low work pressure of 0.01 MPa.

• Jacket Pressure: The steam jacket operates at a pressure of 0.4 MPa, providing heat to maintain the fatty acids at the required temperature.

• Working Temperature: The fatty acids are maintained at a working temperature of 200℃ within the tank.

• Jacket Temperature: The steam jacket is heated to 160℃ to provide the necessary thermal energy for the flash separation process.

• Equipment Size: The size of the tank is determined based on the required production capacity, ensuring efficient and scalable operation.

• Production Standard: Manufactured in compliance with GB150-1998 《Shell and Tube Heat Ex - changer Vessels》, ensuring the equipment meets stringent safety and quality standards.

Fatty Acid Flash Separation Tank Performance Advantages

• Efficient Separation: The flash separation process ensures rapid and efficient removal of gases from the fatty acids, improving product quality.

• Durable Construction: The 00Cr17Ni14Mo2 stainless steel material ensures long - term reliability and minimal maintenance requirements.

• Stable Operation: The tank is designed for stable and continuous operation, with precise control of temperature and pressure parameters.

• Energy - Efficient Heating: The steam jacket system ensures efficient heat transfer, minimizing energy consumption while maintaining optimal separation conditions.

• High - Purity Outputs: The separation process ensures that the fatty acids are of high purity, suitable for further processing or sale as valuable products.

Fatty Acid Flash Separation Tank Applications

The Fatty Acid Flash Separation Tank is widely used in chemical processing plants, biodiesel production facilities, and other industrial settings where fatty acid processing is required. It is typically installed after the hydrolysis or refining stages to remove residual moisture and gases from the fatty acids. The high - purity fatty acids produced can be used in various industries, including soap manufacturing, cosmetics, and chemical production. Its design and specifications make it suitable for integration into both new and existing processing facilities, enhancing their overall efficiency and product quality.
