Crude Glycerol Heater

Crude Glycerol Heater Function and Working Method

The Crude Glycerol Heater operates by circulating steam through a jacket surrounding the heating chamber. Crude glycerol flows through the chamber, where it absorbs heat from the steam - heated jacket. This indirect heating method efficiently raises the temperature of the crude glycerol to the desired level, typically around 143℃ , without direct contact between the glycerol and steam.

Crude Glycerol Heater Material and Construction

Constructed from 00Cr17Ni14Mo2 stainless steel, the Crude Glycerol Heater combines excellent corrosion resistance with high - temperature strength. This material choice ensures that the heater can withstand the rigorous conditions of continuous operation, including exposure to high - temperature steam and crude glycerol.

Crude Glycerol Heater Key Features

• Working Method: Heats crude glycerol indirectly using steam circulating through a jacketed chamber.

• Material: Made from 00Cr17Ni14Mo2 stainless steel, ensuring durability and resistance to corrosion.

• Media: Designed to heat crude glycerol and uses steam as the heating medium.

• Work Pressure: Operates at a work pressure of 0.4 MPa.

• Jacket Pressure: The steam jacket operates at a pressure of 0.25 MPa.

• Working Temperature: The crude glycerol is heated to a working temperature of 143℃ .

• Jacket Temperature: The steam jacket maintains a temperature range of 40 - 90℃ .

• Equipment Size: The size of the heater is determined based on the required production capacity.

• Production Standard: Manufactured in compliance with GB150-1998 《Shell and Tube Heat Exchanger Vessels》, ensuring the equipment meets stringent safety and quality standards.

Crude Glycerol Heater Performance Advantages

• Efficient Heating: The jacketed design ensures efficient transfer of heat from the steam to the crude glycerol, achieving rapid and uniform temperature adjustment.

• Durable Construction: The 00Cr17Ni14Mo2 stainless steel material ensures long - term reliability and minimal maintenance requirements.

• Stable Operation: The heater is designed for stable and continuous operation, with precise control of temperature and pressure parameters.

• Energy - Efficient Operation: The steam heating system ensures efficient heat transfer, minimizing energy consumption while maintaining optimal heating conditions.

• High - Purity Outputs: The indirect heating method prevents contamination of the crude glycerol, maintaining its purity and quality throughout the heating process.

Crude Glycerol Heater Applications

The Crude Glycerol Heater is widely used in biodiesel production facilities, chemical processing plants, and other industrial settings where crude glycerol processing is required. It is typically installed before purification or refining stages to ensure the crude glycerol is at the optimal temperature for further processing. Its design and specifications make it suitable for integration into both new and existing processing facilities, enhancing their overall efficiency and product quality.
