Back Pressure Vessel

Back Pressure Vessel Function and Working Method

The Back Pressure Vessel operates by receiving high - pressure steam from the main steam line. Inside the vessel, the steam is distilled and regulated to the required pressure and temperature levels for downstream processes. The vessel acts as a central distribution point, ensuring that steam is efficiently directed to different process points while maintaining consistent pressure and temperature. This helps optimize energy usage and ensures that each process receives the appropriate amount of steam for its specific requirements.

Back Pressure Vessel Material and Construction

Constructed from Carbon Steel Grade 151 in accordance with BS 1501 Pt.1, the Back Pressure Vessel combines strength and durability. The carbon steel material ensures that the vessel can withstand the high pressures and temperatures associated with steam distribution. The vessel is designed with a hydraulic door sealing method, ensuring airtight closure and preventing steam leakage.

Back Pressure Vessel Key Features

• Working Pressure: The vessel is designed to operate at a working pressure of 3.5 kg/cm², ensuring it can handle the steam requirements of various industrial processes.

• Working Temperature: It is capable of withstanding a working temperature of 150℃ , making it suitable for high - temperature steam applications.

• Outside Diameter: Available in diameters of 1200 mm and 1500 mm to accommodate different installation requirements and steam capacities.

• Capacity: Each unit has a capacity of 12 m³, providing sufficient volume for steam storage and distribution.

• Body Thickness: The vessel body has a thickness of 16 mm, ensuring robustness and longevity under operational conditions.

• Sealing Method: Equipped with a hydraulic door sealing system, ensuring airtight closure and preventing steam leakage.

• Material: Made from Carbon Steel Grade 151 to BS 1501 Pt.1, ensuring strength and durability.

• Size of Man Hole: Features a manhole with a diameter of 800 mm, facilitating easy access for maintenance and inspection.

Back Pressure Vessel Performance Advantages

• Efficient Steam Distribution: The Back Pressure Vessel ensures optimal distribution of steam to various process points, maintaining consistent pressure and temperature.

• Durable Construction: The carbon steel material and robust design ensure long - term reliability and minimal maintenance requirements.

• Airtight Sealing: The hydraulic door sealing method prevents steam leakage, ensuring efficient operation and safety.

• Easy Maintenance: The manhole provides easy access for inspection and maintenance, reducing downtime and operational costs.

Back Pressure Vessel Applications

The Back Pressure Vessel is widely used in industries that rely on steam for various processes, such as palm oil processing, food processing, chemical manufacturing, and more. It is typically installed as part of a central steam distribution system, ensuring that steam is efficiently delivered to different process points throughout the facility. By maintaining optimal steam pressure and temperature, the Back Pressure Vessel contributes to the overall efficiency and productivity of industrial operations.
