Atmospheric Leg Pool

Name: Atmospheric Leg Pool
Brand: Zhengzhou YAHUA Cereals and Oils Engineering Co.,Ltd.
Price: 4500000 USD

The Atmospheric Leg Pool is a specialized piece of equipment used in industrial fluid management systems. Its primary function is to facilitate the discharge of liquids from higher - level equipment into a lower - level pool using the siphon principle. This gravity - driven method ensures efficient liquid transfer without the need for additional power, while also preventing gas ingress into the system to maintain operational safety and stability.

Get a Quote 

Atmospheric Leg Pool Specification

Equipment Name	Atmospheric Leg Pool
Working Method	A Water Tank Related to a Drainage Device That Operates Using the Siphon Principle (Without Power) the Liquid in the Equipment Needs to Be Discharged into a Lower Level Pool. When the Liquid Level in the Equipment Is Higher Than That in the Atmospheric Leg Pool, The Liquid Flows Towards the Pool Through a Long Pipeline Similar to the "Atmospheric Leg" Under the Action of Gravity. There Is No Need for Additional Power to Drive the Liquid Flow in the Pipeline, And It Can Prevent Gas from Entering the Equipment System, Ensuring the Normal Operation and Safety of the System.Material
Media	Crude Glycerin, Steam
Workpressure	Normal
Working Temperature	70℃
Equipment Size	According Capacity

Atmospheric Leg Pool Function and Working Method

The Atmospheric Leg Pool operates based on the siphon principle. When the liquid level in the connected equipment rises above the level in the atmospheric leg pool, gravity induces a pressure difference that drives the liquid flow. The liquid travels through a long pipeline, known as the "atmospheric leg," into the pool. This natural flow eliminates the need for pumps or other power sources, reducing energy consumption and operational costs. The design also includes features to prevent gas from entering the system, ensuring smooth and safe operation.

Atmospheric Leg Pool Material and Construction

Constructed from durable materials suitable for the specific application, the Atmospheric Leg Pool is designed to resist corrosion and withstand continuous operation. The choice of material depends on the type of liquid being handled, ensuring compatibility and longevity.

Atmospheric Leg Pool Key Features

Working Method: Utilizes the siphon principle to discharge liquids from higher - level equipment into a lower - level pool via gravity, without requiring additional power.
Media: Designed to handle various liquids, including crude glycerin and steam.
Work Pressure: Operates under normal pressure conditions.
Working Temperature: Maintains a working temperature of 70℃ , ensuring the liquid remains at the desired condition for transfer.
Equipment Size: The size of the pool is determined based on the required production capacity and system layout, ensuring efficient and scalable operation.

Atmospheric Leg Pool Performance Advantages

Energy - Efficient Operation: The gravity - driven siphon principle eliminates the need for pumps or other power sources, reducing energy consumption and operational costs.
Stable and Safe Operation: The design prevents gas ingress into the system, ensuring stable and safe operation without unexpected interruptions.
Low Maintenance: The lack of moving parts and the simple working principle result in minimal maintenance requirements.
Flexible Integration: The atmospheric leg pool can be easily integrated into existing fluid management systems, enhancing their efficiency and reliability.

Atmospheric Leg Pool Applications

The Atmospheric Leg Pool is widely used in various industries, including chemical processing, food and beverage production, and palm oil processing. It is particularly useful in systems where liquids need to be transferred between different levels without additional energy input. By incorporating this equipment, facilities can optimize their fluid management processes, improve energy efficiency, and ensure the safe and stable operation of their systems.
